Fronius
Wattpilot Home 22 J
Solar-smartEco & Next-Trip modesOCPP 1.6
Solar-surplus charging from as low as 1.38 kW, integrated into Fronius Solar.web. On single-phase, the 22 kW model charges at up to 7 kW.
22 kWmax power
2 yrwarranty
IP65enclosure
Solarcharging
Supplied and installed by our CEC-accredited team across Queensland.
What makes it different.
Fronius Wattpilot Home 22 J charges from solar surplus from as low as 1.38 kW, integrated into Fronius Solar.web with Eco and Next Trip modes. It's untethered, so you use your own Type 2 cable. On single-phase it charges at up to 7 kW.
How it works, simply: a smart charger measures what your solar is producing and what your home is using, then adjusts the car's charging current so it soaks up surplus solar rather than exporting it.
It suits Fronius inverter owners who want the charger, solar and battery in Solar.web.
For Queensland conditions: the manufacturer specifies an operating range of -25 ºC to +40 ºC, and its enclosure rating is IP 65. In hot climates many systems reduce output at the top of their range, so we install out of direct afternoon sun with clearance for airflow wherever possible.
Why we install it.
Low solar threshold
Starts solar charging from 1.38 kW of surplus.
Eco and Next Trip
Charge cheaply, or be ready by a set departure time.
Solar.web
Integrated with Fronius monitoring.
OCPP 1.6
Open protocol support.
The full spec sheet.
Charging
| Variants | WATTPILOT HOME 22 J |
|---|---|
| Phase | Both |
| Rated power | 22 kW |
| Rated current | 6-32 A |
| Charging modes | Eco Mode, Next-Trip Mode (both use Solar Surplus), Time Scheduler |
| Solar Smart Charging | Yes |
| 3 to 1 phase smart switching | Yes |
| Bi-directional | No |
Connectivity
| Internet connection | Yes |
|---|---|
| App control | Yes |
| OCPP1.6 compatible | Yes |
| Multi-user support | No |
| PIN/physical lock | Yes |
| Display | No |
Installation
| Enclosure dimensions | 287 × 155 × 109 mm |
|---|---|
| Weight | 2.3 kg |
| IP rating | IP 65 |
| Operating temperature | -25 ºC to +40 ºC |
| Country of manufacture | Austria |
Warranty
| Warranty | 2 years |
|---|
Build the complete system.
Products from other categories that work well alongside the Wattpilot Home 22 J.
What warranty does the Fronius Wattpilot Home 22 J have?
The manufacturer warranty is 2 years. Terms may require product registration. We register it for you.
Can the Wattpilot Home 22 J be installed outside?
The manufacturer lists IP 65. In Queensland we still avoid direct afternoon sun where possible, because heat can reduce performance, and we'll recommend the best spot during the site visit.
How fast will it charge my car?
Charge speed is limited by the charger, your supply (single- or three-phase) and your car's onboard charger, whichever is lowest. We'll check all three.
Let's talk Wattpilot Home 22 J.
Tell us about your property and we'll quote the Fronius Wattpilot Home 22 J as part of a system designed for your home.
0402 180 144 · [Email]
Request a quote
Specifications are indicative, based on manufacturer datasheets and SolarQuotes comparison data (2026), and vary by model and size. Images are official manufacturer images. Final product selection depends on your site assessment, network rules and availability. Brand availability to be confirmed by Countryside Solar. Sources: solarquotes.com.au (page), solarquotes.com.au (page), solarquotes.com.au (datasheet), fronius.com (page).
