Wallbox
Pulsar Max
Solar-smartEco-smartOCPP 1.6
A palm-sized charger weighing just 1.3 kg, with Eco-smart solar modes. *5-year warranty applies to units sold after October 2025.
7.4 kWmax power
5 yrwarranty
IP55enclosure
Solarcharging
Supplied and installed by our CEC-accredited team across Queensland.
What makes it different.
Wallbox Pulsar Max is a palm-sized charger weighing just 1.3 kg, with Eco-smart solar charging modes and OCPP 1.6 support. Per SolarQuotes, the 5-year warranty applies to units sold after October 2025.
How it works, simply: a smart charger measures what your solar is producing and what your home is using, then adjusts the car's charging current so it soaks up surplus solar rather than exporting it.
It suits drivers who want a compact, design-led charger with solar modes.
For Queensland conditions: the manufacturer specifies an operating range of -25 ºC to 50 ºC, and its enclosure rating is IP 55. In hot climates many systems reduce output at the top of their range, so we install out of direct afternoon sun with clearance for airflow wherever possible.
Why we install it.
Compact
One of the smallest chargers in our range.
Eco-smart
Solar charging modes (with the appropriate meter).
Tethered cable
5 m standard, 7 m optional.
myWallbox app
Scheduling and control.
The full spec sheet.
Charging
| Variants | Pulsar Max single phase Pulsar Max three phase |
|---|---|
| Phase | Single-phase |
| Rated power | 7.4 kW |
| Rated current | 32 A |
| Charging modes | Power boost, Eco-smart, Eco-mode |
| Solar Smart Charging | Yes |
| 3 to 1 phase smart switching | Unknown - manufacturer unresponsive |
| Bi-directional | No |
Connectivity
| Internet connection | Yes |
|---|---|
| App control | Yes |
| OCPP1.6 compatible | Yes |
| Multi-user support | Yes (Super-user can create multiple user profiles for different people) |
| PIN/physical lock | Yes |
| Display | No |
Installation
| Enclosure dimensions | 198 x 201 x 99 mm |
|---|---|
| Weight | 1.3 kg |
| Charge cable length | 5 meters (optional 7 meters) |
| IP rating | IP 55 |
| Operating temperature | -25 ºC to 50 ºC |
| Standby power consumption | 5W |
| Country of manufacture | Spain |
Warranty
| Warranty | 5 years (post-Oct 2025) |
|---|
Build the complete system.
Products from other categories that work well alongside the Pulsar Max.
What warranty does the Wallbox Pulsar Max have?
The manufacturer warranty is 5 years (post-Oct 2025). Terms may require product registration. We register it for you.
Can the Pulsar Max be installed outside?
The manufacturer lists IP 55. In Queensland we still avoid direct afternoon sun where possible, because heat can reduce performance, and we'll recommend the best spot during the site visit.
How fast will it charge my car?
Charge speed is limited by the charger, your supply (single- or three-phase) and your car's onboard charger, whichever is lowest. We'll check all three.
Let's talk Pulsar Max.
Tell us about your property and we'll quote the Wallbox Pulsar Max as part of a system designed for your home.
0402 180 144 · [Email]
Request a quote
Specifications are indicative, based on manufacturer datasheets and SolarQuotes comparison data (2026), and vary by model and size. Images are official manufacturer images. Final product selection depends on your site assessment, network rules and availability. Brand availability to be confirmed by Countryside Solar. Sources: solarquotes.com.au (page), solarquotes.com.au (datasheet), wallbox.com (page).
